PCB MANUFACTURING CAPABILITY
Please contact us for more details about production, and we will answer your questions.
Technology Project Process Capability Technology Project Process Capability
Plate type FR-4 glass fiber board
Aluminum substrate
Copper substrate
Curvature 0.5% (350X350)
Thermal Conductivity 1.0w/1.5w/2.0w/4.0w/8.0w/122w Test withstand voltage AC1500-4000V
Substrate thickness 0.2-5.0mm Copper foil thickness 18um/35um/70um/105um
Surface treatment Lead-free tin
Immersion gold
OSP antioxidant
Forming method CNC computer gong
Die punch
Computer V-CUT
Biggest size 1500x500mm Shape tolerance CNC: ± 0.1-0.15mm
Die punch: ± 0.1mm
Laser cutting: 0.05mm
Smallest size 5x5mm
Minimum line width 0.1mm (4mil) Solder mask type White oil
various color solder resist oil
Minimum line spacing 0.1mm (4mil) Production Process Exposure process
Minimum aperture 0.25mm Monthly capacity 30,000 square meters
E-T test 100% computer open and short test Delivery time Sample: 5-6 days
Batch: 8-12 days
PCBA MANUFACTURING CAPABILITY
Please contact us for more details about production, and we will answer your questions.
Max Size Value
Maximum board 510mm * 460mm
Maximum plate thickness 5mm
Minimum plate thickness 0.2mm
Maximum placement part weight 150g
Maximum part height 25mm
Maximum part size 150mm * 150mm
Maximum part placement accuracy (100QFP) 25um @ IPC
smallest size Value
Minimum Chip Parts 01005 Package
Minimum lead part pitch 0.3pitch
Minimum ball part (BGA) pitch 0.25pitch
Minimum spherical part (BGA) ball diameter 0.25mm
Maximum Capacity Value
Maximum production capacity 300 million parts / month
Specialty BGA placement and rich POP process capability
CERTIFICATIONS
The company has obtained ISO9001: 2015 certification ,IATF 16949 certification,UL (E354470) certification,and High-Tech Enterprise certification.
